• Metric frame motor to AS1359
• 0.18kW to 18.5kW
• Totally Enclosed Fan Cooled (IC411)
• Meets AS1359.5 Minimum Efficiency
• Performance Standard, table B2
• 380~415 Volts 3 Phase 50 Hz (other supplies on request)
• Class F insulation with a Class B temperature rise
• Continuous rated, duty type S1
• Lightweight Alloy Frame motor with top mounted terminal box
• IP55 protection rating
• Finish colour gloss Teal
• Mounting available – Foot, Foot and flange (C and D types), Flange (C and D types), Pad
• Wide range of options available
• 2 year warranty

• Wide Power Range provides options for various industrial applications, accommodating different power needs
• Totally Enclosed Fan Cooled ensures optimal cooling and protection, contributing to a longer lifespan for the motor and reliable performance
• Meets Efficiency Performance Standards per-table B2 which maximizes energy efficiency, reducing operational costs and minimizing environmental impact
• Adaptability to Electrical Environments operates at 380~415 Volts 3 Phase 50 Hz (with options for other supplies upon request), enabling compatibility with diverse electrical systems
• Class F Insulation with Class B Temperature Rise enables reliable performance in demanding conditions, ensuring safe operation under elevated temperatures
• Continuous Rated, Duty Type S1 designed for nonstop operation, making it ideal for applications requiring continuous-duty cycles
• Lightweight Alloy Frame with Top Mounted Terminal Box simplifies installation and handling, enhancing convenience during setup and maintenance
• IP55 Protection Rating provides superior resistance to dust, dirt, and water ingress, ensuring reliable performance in harsh environments
• Versatile Mounting Options offers flexibility in installation configurations, allowing for easy integration into different setups

TECO-MAX-Alloy-Catalogue-MA-122015t

No software downloads.

Download Drawings

Listing can be filtered by using the Motor Selector

Download Datasheets

Listing can be filtered by using the Motor Selector
